Features
Collet-type fastening to shaft outer diameter provides excellent concentricity.
Equipped with buffer cushion for shock absorption inside the nozzle.
Customizable according to desired pad specifications.
Product Inquiry
Technical Data
| Item | Specification |
|---|---|
| Size | Φ 9 x 43.2 mm |
| Weight | Approx. 15g |
| PAD Holder ~ Mount Body Resistance | 5Ω or less |
| Buffer Tension | 1) Length: 2mm 2) Force: 150g ±20% (at 1mm compression) |
Dimensional Drawing
![Collet Buffer Nozzle [CBN]](/images/migrated/Group-96-c287f599a7.webp)
Order Number
![Collet Buffer Nozzle [CBN]](/images/migrated/Frame-92-8bfecb0fb6.svg)
Key Features
![Collet Buffer Nozzle [CBN]](/images/migrated/Group-110-386cddc5b7.webp)
Integrated Spring Cushion
The integrated spring cushion inside the nozzle minimizes shock to the product during pickup and allows for adjustable pressing pressure.
