MONO 5.9T
Single-axis linear motion in a 5.9 mm-wide body. A direct-drive picker for closely spaced pick-and-place layouts.
Compliance information
Please contact your sales representative for certification documents.
Company certifications
- ISO 9001Quality management
- ISO 14001Environmental management
- ISO/IEC 27001Information security management
- ISO 45001Occupational health and safety management
The specification lists a 93 mm body height; the CAD envelope is 116 mm including protrusions. The accompanying dimension drawing contains a different height, so final mounting dimensions require an approved drawing.
The details behind your design.
Final specifications are based on approved drawings.
| Model | MONO-5.9T-10ST |
|---|---|
| Drive configuration | Linear motor Z axis |
| Body width | 5.9 mm |
| Stroke | 10 mm |
| Body depth | 39 mm |
| Specified body height | 93 mm |
| Total mass | 58 g |
| Rated force, Z axis | 2.12 N |
| Motor supply voltage | 24 V DC |
| Position repeatability, Z axis | ≤ 1 μm |
| Encoder resolution, Z axis | 1.25 μm |
Rated force excludes the anti-drop spring and moving-part weight. Specified body height and the CAD envelope cover different boundaries.
Get the engineering files.
Before selecting your picker.
Can I use the 3D dimensions for manufacturing?
The 3D model is for evaluation. Its envelope includes shafts and protrusions and may differ from body dimensions. Use approved PSMP drawings for manufacture and ordering.
How do I check the shaft and nozzle?
MONO 5.9T is available in type 01 only; there is no type 02. Confirm shaft tolerances and the mounting arrangement for customer-made nozzles.
Need pin maps or cable documentation?
Pin maps can vary with current and voltage even within a family. Request the model-specific pin map and cable drawing before making cables.
